The Sierra MP39100 Ignition Switch replaces Johnson / Evinrude 386545 for Johnson / Evinrude Outboard applications. It provides key-operated control of the engine ignition and starting circuits.
Back Up Nut:Â Brass
Face Nut:Â Hex Black Plastic
Hole Size:Â 7/8"
Length:Â Long: 1 1/8" maximum panel thickness
Material:Â Marine grade glass-filled Polyester
Rated Ignition:Â 15 Amp @ 12v DC
Rated Solenoid:Â 30 Amp @ 12v DC
Terminal Type:Â 5 Screw Tab
Type:Â 3 Position Magneto
Switch Positions:Â Off - Run - Start
Maximum corrosion protection - eliminates oxidation
Inner seal between cylinder lock and contact plate
Non-conductive housing eliminates potential shorts
Need help with fitment? Contact us with your engine model and serial number and we'll help check suitability.
What is Sierra MP39100?
Sierra MP39100 is an aftermarket switch for Johnson / Evinrude Outboard applications.
Which part numbers cross-reference Sierra MP39100?
This listing cross-references Johnson / Evinrude 386545 and Johnson / Evinrude 0378238. See the Cross References & Alternative Products section above for linked alternatives where available.
How can I check whether Sierra MP39100 fits my Johnson / Evinrude Outboard application?
Contact us with your engine model and serial number and we'll help check suitability.
