VC500 Vertical Powered Capstans 12V
Designed to suit vessels up to 27m (88ft) the Muir range of capstans provide reliable and heavy duty operation for mooring, warping and anchoring for all recreational and commercial applications.
Efficient and quick they can be installed independently or as a complete system with windlasses.
Manufactured to the highest quality standard, featuring heavy chrome and gear drive assembly.
Accommodating varying deck thicknesses, they are popular for line hauling and fishing purposes. Available in 12 volt
Features:
- Deck hugging snag free design
- Unit can be mounted horizontally
- Polished 316 Stainless steel on some models
- Capstan has knurled grip
- Heavy duty dual direction motor in 12 & 24
- Stainless steel shaft
- Stainless steel mounting bolts
- Installation/Operation booklet
Technical Specifications:
- Recommended vessel length: 5-9m
- Power supply options: 12V DC
- Recommended Muir circuit breaker: 80A (12V)
- Motor (watts): 550W
- Amps workload: 75A (12V)
- Max load: 150kg
- Workload: 50kg
- Max line speed: 25m/min
- Compatible rope sizes: 10mm (3/8") & 13mm (1/2")
- Auto anchor compatible: No
- Weight: 9kg
