Sionyx Marine Nightwave Night Vision Cameras
Nightwave is an ultra low-light marine navigational camera built around SIONYX’s patented Black Silicon CMOS sensor. It allows mariners of all levels to easily spot obstacles and debris in moonless starlight without white light or expensive thermal cameras – navigating safely, avoiding collisions, and maximizing time on the water. IP67-rated, it’s built to operate in the toughest marine environments.
Nightwave’s flexible mounting and video streaming setups allow both seamless integration with major brand MFDs and the option to view live video on your mobile device – so you can navigate confidently in the dark from any vessel with clear color digital night vision.
CAPABLE - <1 mlx moonless starlight sensitivity allows you to see well beyond human eyesight.
AWARE - Stable 44º field of view increases situational awareness to spot unexpected obstacles, debris, markers, vessels, and more.
RUGGED - IP67 rating protects against water, sand, salt, and dust. Dry nitrogen purged to prevent lens fogging. Safely use Nightwave in inclement weather conditions.
CONNECTED - Flexible installation options allow seamless integration with major brand MFDs and WiFi video streaming to the new SIONYX mobile app.
With the SIONYX Nightwave, you will be able to spot a man-sized object from 150m away*. The 44° field of view increases situational awareness so you can spot unexpected markers, vessels, land formations and more. IP67 rated, submersible to 1 metre for 30 minutes, you can safely use Nightwave in inclement weather conditions.
• Can detect (man) sized objects upto 150m with a 1/4 moon*.
• 30Hz FPS @ 1280 x 1024 XQE-1350 BSI CMOS sensor.
• 16mm F/1.4 lens
• 30Hz FPS @ 640 x 640 NTSC video out.
• 10m to infinity focus range with a 400-1200NM visible spectrum.
• SMA / BNC / RCA analogue video connections.
• Wireless via WiFi + Bluetooth.
• UV resistant polycarbonate.
• Multiple mounting options.
• Operating temp: -20°C to +50°C.
• 5m Tinned copper wire.
• Shock and vibration: IEC60945 (V15G | H:9G) |IK08.
• Protection Rating: IP67.
• 12V DC / USB 5V.
Kit Includes:
• SIONYX Nightwave Ultra Low-Light Marine Camera
• Analogue Video Cable [5M]
• SMA to BNC adapter
• BNC to RCA adapter
• Power Fuse & Fuse Holder
• Digital Video Cable USB (3m)
• Base Gasket
• Mounting Hardware
• User Manual
• Install Template
