DW08 12V Drum Winch - Rope & Chain

0 review Write a Review
DW08 12V Drum Winch - Rope & Chain  Muir’s patented range of drum winches varies from Auto Free Fall, Power Up & Power Down, as well as Manua…
SKU: MW-F331041
$1,589.01

DW08 12V Drum Winch - Rope & Chain

$1,589.01

DW08 12V Drum Winch - Rope & Chain

Muir’s patented range of drum winches varies from Auto Free Fall, Power Up & Power Down, as well as Manual Release Free Fall.

They are all available to you in one unit making anchoring easy, fast and reliable. They do not require any more space than a standard drum winch.

Muir drum winches suit boats from 4 to 14 metres (13–47ft), with a larger drum capacity than any other free falls on the market.

Features:

  • Marine grade 316 stainless steel drum
  • Heavy duty, marine grade, dual-direction motor
  • Superior, heavy-duty Italian drivetrain
  • Compact anchoring system to suit boats with no anchor rode storage
  • Simple installation

Technical Specifications:

  • Recommended vessel length: 5-8m
  • Power supply options: 12V DC
  • Recommended Muir circuit breaker: 100A (12V)
  • Motor (watts): 800W
  • Amps workload: 80A (12V)
  • Max load: 180kg
  • Workload: 60kg
  • Max line speed: 33m/min
  • Compatible chain sizes: 6mm (1/4") & 8mm (5/16")
  • Compatible rope sizes: 8mm (5/16")
  • Auto anchor compatible: No
  • Weight: 15kg

Operating & Installation Manual

*Rope & Chain not included as pictured
