HR2500 Cheetah Compact Horizontal Windlasses

The powerful Compact range of horizontal windlasses provides the perfect alternative to vertical models for all recreational, commercial and fishing vessels up to 25 metres.

Compact series of horizontal windlasses are ideal for installations where chain locker space is at a premium or not easily accessible.

These housing types enclose the powerful and heavy-duty motor and gearbox, waterproofing and protecting them from the harsh elements.

All running gear is designed for durability and performance, manufactured from marine-grade stainless steel with luxury chrome.

Features:

  • Brushed finished 316 stainless steel housing
  • Polished stainless steel components
  • High tensile stainless steel shaft
  • Heavy duty, marine grade, dual-direction motor
  • Superior, heavy-duty Italian drive train
  • Chain pipe & peeler
  • Independent gypsy and capstan operation
  • Front double twin footings
  • Suits multiple global chain standards
  • Deck isolation pad

Technical Specifications:

  • Recommended vessel length: 13-17m
  • Power supply options: 12/24V DC
  • Recommended Muir circuit breaker: 150/100A (12/24V)
  • Motor (watts): 1500W
  • Amps workload: 150/75A (12/24V)
  • Max load: 1200kg
  • Workload: 400kg
  • Max line speed: 28m/min
  • Compatible chain sizes: 8mm (5/16") & 10mm (3/8")
  • Compatible rope sizes: N/A
  • Auto anchor compatible: Yes
  • Weight: 36kg

Instruction Manual

Deck Manual
