DFF12 12V Free Fall Drum Winch - Rope & Chain
Muir’s patented range of drum winches varies from Auto Free Fall, Power Up & Power Down, as well as Manual Release Free Fall.
They are all available to you in one unit making anchoring easy, fast and reliable. They do not require any more space than a standard drum winch.
Muir drum winches suit boats from 4 to 14 metres (13–47ft), with a larger drum capacity than any other free falls on the market.
All Muir free falling drum winches are supplied with a circuit breaker, reversing solenoid pack, helm control switch and fascia panels, as well as simple tools & hardware for an easy 30 second adjustment from Auto Free Fall; to manual free fall and power up/power down options.
Features:
- Muir’s patented Auto Freefall or Manual Release Freefall is available in one unit!
- Mechanical Auto & Manual Release Freefall means no troublesome electronics must be mounted on the Drum or your chain locker
- Drum Shaft on a serviceable bearing centre for smooth, hassle-free operation even under full load.
- Muir’s drum brake means no over-run during Freefall
- Fast, easy and reliable anchoring with a Muir Drum Winch
- Large capacity drum
- Compact Anchoring system to suit boats with no anchor rode storage
- 316 stainless steel drum
- Superior, heavy-duty Italian drive train
Technical Specifications:
- Recommended vessel length: 10-12m
- Power supply options: 12V DC
- Recommended Muir circuit breaker: 150A (12V)
- Motor (watts): 1500W
- Amps workload: 150A (12V)
- Max load: 312kg
- Workload: 104kg
- Max line speed: 33m/min
- Compatible chain sizes: 8mm (5/16") & 10mm (3/8")
- Compatible rope sizes: 10mm (3/8")
- Auto anchor compatible: Yes
- Weight: 32kg
